SX-TVH1-5MP is an analog high-definition interface HD-TVI to HDMI output converter and has a loop output. The input end has a built-in equalizer and can complete the long-distance extension function. And the product is compatible with AHD analog signal input
1.Convert TVI/AHDto HDMI, with 1xlooping TVI/AHD output 2.Support TVI/AHD 720P, 1080P input 3.Max output support HDMI 1080p@60Hz 4.Support transmission distance up to 300m over coaxial cable
Box Contents 1x SX-TVH1 1x 5V/1A DC Power Supply 1x User manual
Video Input Connectors: 1x TVI/AHD
Video Output Connectors: 1x TVI/AHD, 1x HDMI
Dimensions: 95x 94x 28 mm
Shipping weight: 0.6kg
Operating Temperature: -10 to +45℃(14 to +113℉)
Power Supply: 5V1A
Casing Materia: Iron
