SX-HSD6 is a HDMI to 12G-SDI output converter which convert HDMI signals to 12G-SDI pure digital format in 4K@60Hz 4:2:2. Auto format detection for 12G-SDI,3G-SDI, HD-SDI and SD-SDI. **NOTE: This is not a bi-directional converter. DO NOT use for SDI ⟶ HDMI conversion
1.Support HDMI resolution up to 4K@60Hz 4:2:2 2.Bandwidth upto 12Gbps 3.Support Long SDI cable runs up to 80m for 12G 4K@60Hz 4:2:2, 6G 4K@30, 120m 3G 1080p 4.Support HDCP2.2/1.4
5.1x HDMI loop out for cascading
6.Support EDID management
7. Support PCM2.0 audio format
Box Contents 1x SX-HSD6 1x 12V/1A DC Power Supply 1x User manual
Video Input Connectors: 1x SDI(BNC)
Video Output Connectors: 2x HDMI ( Standard Type A connector )
Dimensions: 96.8x80x21.4mm
Shipping weight: 0.6kg
Operating Temperature: -5 to +35℃(+23 to +95℉)
Power Supply: 12V1A
Casing Materia: Iron
