1.Advanced HDBaseT™ technology offering uncompressed video and audio with zero latency 2.1x HDMI Loop out  for integrating local displays or cascading to multiple devices 3.2x HDMI outputs on the Receiver for TVs connected a further distance away from your HDMI source device 4.Extends HDMI 1080p up to a distance of 70m/230ft over a single CAT cable 5.Extends 4K UHD video up to 40m/130ft 4K@60HZ 4:4:4 6.Supports HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD Master Audio transmission (TX to RX) 7.Bi-directional IR, RS232 pass-through 8.Supports bi-directional PoC (Receiver powered by Transmitter or Transmitter powered by Receiver)

9.HDCP 2.2 compliant with smart EDID management

Box contents 1x SX-EX53-TX 1x SX-EX53-RX 1x 24V/1A DC Power Supply 1x IR emitter 1x IR receiver 2x 3-pin Phoenix connector 1x User Manual

Video Input Connectors: 1 x HDMI Type A, 19-pin, female ; 1 x HDBaseT™ RJ45 connector

Video Output Connectors: 3 x HDMI Type A, 19-pin, female ; 1 x HDBaseT™ RJ45 connector

RS-232 serial port: 2 x 3-pin Phoenix connector

IR Input ports: 2 x 3.5mm stereo jack

IR Output ports: 2 x 3.5mm mono jack

Dimensions: 139.4×66.8×20mm

Shipping weight: 1kg

Operating Temperature: -10 to +45℃(14 to +113℉)

Operating Humidity: 5 to 90 % RH (no condensation)

Power Supply: 24V1A

Casing Materia: Iron

FW update Port: 2x Micro USB
