1. Each set includes one transmitter and one reciver

2. Follwing Noth American wallplate standard

3. Use single UTP cable (Cat5e/6) to substitute HDMI cable to achieve long distance transmission

4. Transmission distance reached up to 60 meters under the video format of 1080p

5. Signaling rates up to 2.25Gbits in support of 1080p display

6. With IR control to the source


Box Contents

1x SX-EW60-3DIR

1x User manual

1x IR TX cable

1x IR RX cable

2x 5V/1A DC Power Supply

2x Plastic Front Panel

Video Input Connectors: 1 x HDMI Type A, 19-pin, female ; 1 x RJ45 connector

Video Output Connectors: 1 x HDMI Type A, 19-pin, female ; 1 x RJ45 connector

IR Input ports: 1 x 3.5mm stereo jack

IR Output ports: 1 x 3.5mm mono jack

Dimensions: 115x70x35mm

Shipping weight: 0.26kg

Operating Temperature: -5 to +35℃(+23 to +95℉)

Operating Humidity: 5 to 90 % RH (no condensation)

Power Supply: 5V1A

Casing Materia: Plastic
