SX-SP34 is 4 ports HDMI splitter which distributes a single HDMI source to four simultaneous outputs. And It supports video resolutions up to 8K @ 60Hz 4:4:4; 48Gbps. Compliant with HDMI 2.1 and HDCP 2.2 standards. Route your 8K video sources to 8K displays and 4K displays simultaneously via downscaling.
1. Simultaneously displays one source on up to four displays
2. Support resolutions up to 8K (7680x4320@60HZ YUV 4:4:4)
3.Advance EDID management
4.Support HDMI Audio Formats: LPCM7.1, Dolby Atmos, Dolby Vision, Dolby digital,Dolby TrueHD, DTS,HDR10, HDR10+, HLG
5.Support HDCP2.2/1.4 compliant
6. Support downscaler from 8K to 4K
Box Contents 1x SX-SP34 1x 5V/2A DC Power Supply 1x User manual
2x mounting ear
Video Input Connectors:1 x HDMI Type A, 19-pin, female
Video Output Connectors: 4 x HDMI Type A, 19-pin, female
Dimensions: 150x64.2x17mm
Operating Temperature: -5 to +35℃(+23 to +95℉)
Operating Humidity: 5 to 90 % RH (no condensation)
Power Supply: 5V2A
Casing Materia: Iron
